Adjusting the Frequency
Digital News Production 197
Adjusting the Frequency
The Frequency dials let you adjust the frequency of the three shelves. The
ranges for adjusting the frequency are:
Adjusting the Gain
The Gain dials let you alter the gains of the three shelves. The ranges for
adjusting the gain are (units are in dB):
Adjusting the Mid Band Q
The Mid Band Q lets you alter the octave range for both the Mid Band
Frequency and the Mid Band Gain.
The range for the Mid Band Q is .01 to 10, with 5 as the default.
NOTE: You can double-click any dial to reset the default value.
Dial Range Default
High Pass Frequency 2k Hz to 12k Hz, +/- 12 dB 7k Hz
Mid Band Frequency 100 Hz to 12k Hz, +/- 12 dB 6.5k Hz
Low Pass Frequency 30 Hz to 500 Hz, +/- 12 dB 235 Hz
Dial Range Default
High Pass Gain -12 to +12 0
Mid Band Gain -12 to +12 0
Low Pass Gain -12 to +12 0
