Hardware Preparation and Installation
MVME2502 Installation and Use (6806800R96E)
47
6. Install the board into the appropriate card slot. Make sure that the board is well seated into
the backplane connectors. Do not damage or bend connector pins.
7. Replace the chassis or system cover.
8.
Reconnect the system to the power source and then turn on the system.
When removing the PMC/XMC, hold it by its long side and exert minimal force when pulling
it from the baseboard to prevent pin damage.
