VX76 SOFTWARE USER MANUAL 239
The following is a list of all included Canned Macros by number:
Table 10-1: Canned Macros
No. Name Macro Description Bank Page
1901 Auto Display Filter Turn on Auto Display Filter 20 1
1902 Load Display Filter Loads Display Filter 20 1
1903 Clear Display Filter Clears Display Filters 20 1
1904 Home Home Luminaires 20 1
1905 Home Inten Full Home Luminaires and puts intensity at full 20 1
1906 +5 Add 5% to Intensity 20 1
1907 +10 Add 10% to Intensity 20 1
1908 Sub 1 Hi Lite Off Reselects channels and loads color from sub 1 20 1
1909 Sub 1 Hi Lite Forward
Takes luminaire selection and steps through each channel in
ascending order, bumping each channel to white and then back to
the cue in sub 1.
20 1
1910 Sub 1 Hi Lite Reverse
Takes luminaire selection and steps through each channel in
descending order, bumping each channel to white and then back to
the cue in sub 1.
20 1
1911 Mark Back 1 Cue
Takes the current selection and marks the channels in the previous
cue
20 1
1912 Mark Back 2 Cues Takes the current selection and marks the channels two cues back. 20 1
1913 Park Parks selected channels 20 1
1914 Un-Park Un-Parks selected channels 20 1
1915 Select Park Selects parked channels 20 1
1916 -5 Subtract 5% from Intensity 20 1
1917 -10 Subtract 10% from Intensity 20 1
1918 Palette Hi Lite Off Reselects channels and bumps the color to Color Palette 299. 20 1
1919 Palette Hi Lite Forward
Steps through channel selection in ascending order, bumping the
current channel to the Hi lite color (color palette 299) and putting the
other channels to the background color (color palette 300)
20 1
1920 Palette Hi Lite Reverse
Steps through channel selection in descending order, bumping the
current channel to the Hi lite color (color palette 299) and putting the
other channels to the background color (color palette 300)
20 1
1921 Up Time 0 Sec Sets Up Time for current selection to 0 Seconds 20 2
1922 Up Time 1 Sec Sets Up Time for current selection to 1 second. 20 2
1923 Up Time 2 Sec Sets Up Time for current selection to 2 Seconds 20 2
1924 Up Time 3 Sec Sets Up Time for current selection to 3 Seconds 20 2
1925 Up Time 4 Sec Sets Up Time for current selection to 4 Seconds 20 2
1926 All Time 0 Sec Sets time to all parameters for the current selection to 0 seconds. 20 2
1927 All Time 1 Sec Sets time to all parameters for the current selection to 1 seconds. 20 2
1928 All Time 2 Sec Sets time to all parameters for the current selection to 2 seconds. 20 2
1929 All Time 3 Sec Sets time to all parameters for the current selection to 3 seconds. 20 2
1930 All Time 4 Sec Sets time to all parameters for the current selection to 4 seconds. 20 2
1931 Down Time 0 Sec Sets Down Time for current selection to 0 Seconds 20 2
