8.2.22 Preset Count Value
Preset value for the preset counter can be set.
Preset count value can be set within 0 to 99999999.
Preset counter will not be affected by the indicating unit but it is recommended that one of the
integrating units be set as the indicating unit so that the operating condition of the counter can
be checked.
* Preset output function can be selected. For details, see 0, “Preset Output Function.”
Note Preset counter operates only for foreword direction counts.
Proceed as follows to check or change the preset count value.
■ To change the preset count value:
The following example shows how to change the preset count value from 500 to 1000.
Key operation
Display example
Description
H:
Select "PRESET CNT" in the configuration item selection
MEAS MODE
^PRESET CNT
PRESET FNC
fSELl iENTl
screen.
STEP1
H1:
PRESET CNT
The currently set value (500 in this example) is displayed.
[ЕМЛ
00000500
Then press the [ENЛ key.
fEXTl [ENT]
* Pressing the [EXT] key returns you to the menu screen.
STEP2
H1:
The switch name display at the bottom changes (three keys
PRESET CNT
[UP], [SEL] and [SET]).
00000500
At the same time, the cursor appears.
[ENT]
(The digit on which the cursor is positioned is
[U P] [SELl [SET]
reverse-displayed.)
STEP3
H1:
Move the cursor to the desired digit using the [SEL] key and
PRESET CNT
change the numeric value using the [UP] key.
[SEL]<=>[UP]
00001000
[U P] [SEL] [SET]
Repeat this operation to change the value the to 1000.
When the value has changed to the desired
numeric value, press the [SET] key to set the value temporarily.
STEP4
HI:
When you press the [SET] key, a message confirming you
PRESET CNT
whether the setting is OK is displayed.
00001000
If OK, press the [SET] key. If you want to redo the setting, press
[SET]
OK?
^
(N01 [SET]
the [NO] key.
STEP5-1
HI:
Pressing the [NO] key when you are asked "OK?" causes the
PRESET CNT
setting value to return to the previous value and enables you to
00000500
redo the setting.
[NO]
[U P] [SELl [SET]
STEP5-2(=END)
HI:
Pressing the [ЗЕЛ key when you are asked "OK?" causes the
PRESET CNT
setting value to be determined.
00001000
Then press the [ЕХЛ key. You return to the menu screen.
[ЗЕЛ
Pressing the [ENЛ key enables you to restart
iEXTl iENTl
setting value change operation from a state of 1000.
-
