Changing the fixed output function
Shown below are the procedures for setting the fixed output to ON and setting the fixed current
value/fixed pulse value. The fixed current value and fixed pulse value can be set independently.
Key operation
Display example
Description
M;
Select "FIXED OUT" In the configuration item selection
MEAS MODE
-^FIXED OUT
FIXED CURR
FIXED PULSE
fSELl lENTl
screen.
STEP1
M1:
FIXED OUT
The current setting value (OFF in this example) is set.
[ENT]
OFF
[EXT] [ENT]
Then press the [ENT] key.
* Pressing the [EXT] key returns you to the menu screen.
STEP2
M1:
The switch name display at the bottom changes (three
FIXED OUT
BBi
keys [UP], [DWN] and [SET]).
At the same time, the cursor appears.
[ENT]
[U PI fDWNl [SET]
(The digit on which the cursor is positioned is
reverse-displayed.)
STEP3
M1:
FIXED OUT
Change the selection item using the [UP]/[DWN] key.
When you have selected the desired item, press the [SET]
[UP]/[DWN]
[U P] [DWNl [SET]
key.
STEP4
M1:
When you press the [SET] key, the selected item is set
FIXED OUT
temporarily and a message confirming you whether the
ON
setting is OK is displayed.
[SET]
If OK, press the [SET] key. If you want to redo the setting.
OK?
[NO] [SET]
press the [NO] key.
STEP5-1
M1:
Pressing the [NO] key when you are asked "OK?" causes
FIXED OUT
the numeric value to return to the previous value and
[NO]
BH3
[U P] [DWNl [SET]
enables you to redo the setting.
STEP5-2
M2:
Pressing the [SET] key when you are asked "OK?" causes
FIXED CURR
the fixed current output ON setting to be determined and
@0.0
the fixed current value setting screen to be automatically
[SET]
mA
[EXT] [ENT]
developed.
At the same time, the cursor appears.
(The digit on which the cursor is positioned is
reverse-displayed.)
STEPS
M2:
Move the cursor to the desired digit using the [SEL] key
FIXED CURR
and change the numeric value using the [UP] key.
Repeat this operation to change the value to 12.0mA.
[SEL]<=>[UP]
mA
When the value has changed to the desired
[U P] [SEL] [SET]
numeric value, press the [SET] key to set the value
temporarily.
-
