TOSHIBA i6,F,8iA0i8i6,9,
The display low cut setting can be checked/changed by the following procedure.
Shown below is an example of changing the display cut setting from OFF to ON.
Key operation Display example Description
D: Select "DSP LOW CUT" In the configuration item
MEAS MODE
DAMPING
LOW CUT
ALM mA SET
^DSP LOW CUT
LOW LIMIT
[SEL] [ENT]
selection screen.
STEP1 D4: The current setting value (OFF in this example) is
DSP LOW CUT
OFF
displayed.
[ENT] Then press the [ENT] key.
[EXT] [ENT]
* Pressing the [EXT] key returns you to the menu
screen.
STEP2 D4: The switch name display at the bottom changes
DSP LOW CUT (three keys [UP], [DOWN] and [SET]).
At the same time, the cursor appears.
[ENT]
fU PI [DWNl [SET]
(The digit on which the cursor is positioned is
reverse-displayed.)
STEPS D4: Change the selection item using the [UP]/[DWN]
DSP LOW CUT
B
key.
[UP]/[DWN]
fU PI [DWNl fSETl
When you have selected the desired item, press the
[SET] key.
STEP4 D4: When you press the [SET] key, the selected item is
DSP LOW CUT set temporarily and a message confirming you
ON
whether the setting is OK is displayed.
[SET] If OK, press the [SET] key. If you want to redo the
OK?
IN 01 fSETl
setting, press the [NO] key.
STEP5-1 D4: Pressing the [NO] key when you are asked "OK?"
DSP LOW CUT causes the setting value to return to the previous
[NO]
MH
[U PI [DWN] [SET!
value and enables you to redo the setting.
STEP5-2(=END) D4; Pressing the [SET] key when you are asked "OK?"
DSP LOW CUT causes the setting to be determined.
ON
Then press the [EXT] key. You return to the menu
[SET] screen.
Pressing the [ENT] key enables you to restart
lEXTl lENTl
setting operation from a state of ON.
* The measurement value transmitted from the converter by communication is data
after display low cut processing.
-
87
-
