8.2.12 Switch Position Setting
This section describes how to set the switch position of the converter display.
Setting the switch position enables the display orientation to be kept fixed, regardless of in which
direction relative to the piping the converter is installed.
You can set the switch position by selecting one from four items below.
(1) Switch position: TOP
The infrared switches are located at the top.
□ □
em
FLOW
10.00
IÏ1/S
TOTAL CNT
99999
m3
Infrared switches
(2) Switch position: BOTTOM
The infrared switches are located at the bottom.
FLOW
10.00
m/s
TOTAL CNT
99999
m3
BÜ
□ □
Infrared switches
-
