TOSHIBA 6|F,8,A0,8,6|9
Key operation Display example Description
[SEL]
C2:
RANGE1
3|00000
m/s
ÍUP1 [SELl [SET]
Ready to change the setting value.
Pressing the [SEL] key causes the cursor to move
to the next digit.
[UP]
[SEL]
C2:
RANGE1
looooo
m/s
fUPl fSELl fSETl
Ready to change the setting value.
You can change the setting value by using the [UP]
and [SEL] keys.
In this example. 5.000 m/s is selected.
[SET]
C2:
RANGE1
5.00000
m/s
/
OK?
[NO] [SET]
Pressing the [SET] key causes the data to be set
temporarily. The cursor disappears and a
confirmation message is displayed.
[NO]
C2:
RANGE1
looooo
m/s
[UPl [SEL] [SETl
If you want to cancel the data change here, for
example, because the temporarily set data is
incorrect, press the [NO] key, which causes the
temporarily set data to return to the original setting
value and enables you to change the setting value
again.
[SET]
C2:
RANGE1
5.000
m/s
[EXT] [ENT]
Pressing the [SET] key when data is temporarily set
causes the data to be determined and set.
After the data is set, the cursor disappears,
enabling you to check the setting value.
*ln the case of the flow velocity unit, the value is
automatically rounded to 3 decimal places. In the
case of the actual flow rate unit, the value is
automatically rounded to 3 significant digits.
[EXT]
C:
MEAS MODE
GRANGE TYPE
RANGE 1
RANGE 2
RANGES
RANGE 4
RANGE HYS
[SELl [ENTl
Pressing the [EXT] key returns you to the menu
display screen.
[SEL]
[ENT]
C:
MEAS MODE
OK?^
[NO] [SET]
By pressing the [SEL] key to move an arrow mark to
MEAS MODE and pressing the [ENT] key,
confirmation message is displayed.
If [NO] key is pushed, operation of shift to
measurement mode is canceled.
[SET]
FLOW
002.000
m/s
RANGE1
5.000
m/s
By pressing the [SEL] key, you can terminate the
setting mode and return to the
measurement mode.
-
49
-
