O Detailed configuration
When you select "DETAILED" in the menu configuration selection screen, the check/change menu
0 1 2 3 4 5 6
A Exciting current
setting *1
Meter size *1 Exciting
frequency *1
Flow direction
setting *1
Password *1 Address
setting *1
B Main display
setting
Sub display
setting
Custom
(coefficient) *1
Custom
(unit) *1
LCD density
adiustment
Switch position
setting
C Range type *1 Range 1 *1 Range 2 *1 Range 3 *1 Range 4 *1 Range
hysteresis *1
D Damping
constant Low cut value Current output
setting upon
alarm
occurrence *1
Display low cut
Yes/No
Output low limit
setting *1
E Still water
zero point
adiustment
F
Return to the
measurement
mode
Digital
output 1 *1
Digital
output 2 *1
Digital
input 1 *1
D01 alarm
output state *1
D02 alarm
output state *1
Dl control
signal level
setting *1
G Count rate *1 Pulse width
setting mode *1
Pulse width*1
H Preset count
value *1
Preset output
setting *1
1 High limit alarm
ON/OFF *1
High limit value
setting *1
Low limit alarm
ON/OFF *1
Low limit value
setting *1
J High high limit
alarm ON/OFF
*1
High high limit
value setting
*1
Low low limit
value ON/OFF
*1
Low low limit
value setting
*1
K Fluid empty
alarm *1
Self-diagnosis
Yes/No *1
Alarm output
preset *1
L Limit rate Limit time ___— __________
M Fixed output *1 Fixed current
*1
Fixed pulse *1
N Manual zero
0 0%
Flow value
calculation *1
50%
Flow value
calculation *2
100%
Flow value
calculation *1
Exciting
current
display *2
Note 1 If you enter a wrong password, you are allowed to check the setting value and to perform
calibration for the items with * 1 mark in the table. However you are not allowed to change
the setting and perform calibration for these items.
Note 2 The items with*2, you are only allowed to check the calibration value.
Note 3 For function A2, you are only allowed to check the setting value.
-
