8.2.27 Alarm Output Preset Function Setting
Setting the digital output to "failure alarm output" enables a digital signal to be output when the
converter self-diagnosis function detects a defect.
When setting the digital output, you specify whether empty alarm is to be included in the failure
alarm output targets.
Selection item Description
WITHOUT EMP Empty alarm is not included in failure alarm output.
WITH EMP Empty alarm is included in failure alarm output.
* For other failure alarm targets, see 0 "Self-diagnosis Function Setting."
# Changing the alarm output preset function
Shown below is an example of changing the alarm output preset function from WITH EMP to
гноит EMP.
Key operation Display example Description
K;
MEAS MODE
EMPTY ALM
SELF CHECK
-^ALM PRESET
Select "ALM PRESET" in the configuration item selection
screen.
fSELl [ENT1
STEP1
[ENT]
K3:
ALM PRESET
WITH EMP
[EXn_______[ENT]___
The current setting value (WITH EMP in this
example) is displayed.
Then press the [ENT] key.
* Pressing the [EXT] key returns you to the menu screen.
STEP2 K3:
ALM PRESET
The switch name display at the bottom changes (three
keys [UP], [DWN] and [SET]).
At the same time, the cursor appears.
(The digit on which the cursor is positioned is
reverse-displayed.)
WITH EMP
[ENT]
ÍU P] ÍDWN] [SET]
STEPS КЗ:
ALM PRESET
Change the selection item using the [UP]/[DWN] key.
^H without emp ^H
When you have selected the desired item, press the [SET]
key. [UP]/[DWN]
fU PI [DWN] fSETl
STEP4
[SET]
K3:
ALM PRESET
WITHOUT EMP
OK?
^
____[NO]_______[SET]___
When you press the [SET] key, the selected item is set
temporarily and a message confirming you whether the
setting is OK is displayed.
If OK, press the [SET] key. If you want to redo the setting,
press the [NO] key.
STEP5-1 K3:
ALM PRESET
Pressing the [NO] key when you are asked "OK?" causes
the setting value to return to the previous value and
WITH EMP
enables you to redo the setting.
[NO]
[U P] [DWN] [SET]
STEP5-2(=END)
[SET]
K3:
ALM PRESET
WITHOUT EMP
[EXT]______ ii£0 ____
Pressing the [SET] key when you are asked "OK?" causes
the setting to be determined.
Then press the [EXT] key. You return to the menu screen.
Pressing the [ENT] key enables you to restart
setting operation from a state of WITHOUT EMP.
-
