Using the digital input signal
Remote operations for the totalizer and pulse output can be conducted using the digital input signal.
The following functions in the table can be performed. See 0 “Digital I/O” to select these functions.
Operation with the digital input signal (Initial setting: H level in control level)
Digital
input
(DI)
Functions
DI voltage level
Totalizer and pulse output
Totalizer
Start/Stop
L level
Stops the totalizer and the pulse output.
H level
Start the totalizer and the pulse output.
Totalizer
Reset/Start
H level
Stops and clears (resets) the totalizer.
L level
Start the totalizer and the pulse output.
You can reverse the digital input detective level. For detail, see 8.2.12 “Digital Input Detective
Level.”
* Select H level (1:H LEVEL) :
The operation with the digital input signal is same as the
standard converter shown in the above table.
* Select L level (0:L LEVEL) ; The operation with the digital input signal is same as the
standard converter shown in the below table.
Operation with the digital input signal (Control signal level: L level in control level)
Digital input (DI)
Functions
DI voltage level
Totalizer and pulse output
Totalizer
Start/Stop
L level
Start the totalizer and the pulse output.
H level
Stops the totalizer and the pulse output.
Totalizer
Reset/Start
H level
Start the totalizer and the pulse output.
L level
Stops and clears (resets) the totalizer.
-
119
-
