Key operation Display example Description
STEPS M2:
FIXED CURR
[email protected]
Move the cursor to the desired digit using the [SEL] key
and change the numeric value using the [UP] key.
Repeat this operation to change the value to 12.0mA.
[SEL]<^[UP1
mA
When the value has changed to the desired
[UP] [SEL] [SET]
numeric value, press the [SET] key to set the value
temporarily.
STEP? M2:
FIXED CURR
12.0
When you press the [SET] key, the selected item is set
temporarily and a message confirming you whether the
setting is OK is displayed.
[SET] /
OK?
[NO] ÍSET1
If OK, press the [SET] key. If you want to redo the
setting, press the [NO] key.
STEP8-1
[NO]
M2:
FIXED CURR
@0.0
mA
[UPl [SEL] [SET]
Pressing the [NO] key when you are asked "OK?"
causes the numeric value to return to the previous
value and enables you to redo the setting.
STEP8-2 M3:
FIXED PULSE
Soooo
Pressing the [SET] key when you are asked "OK?"
causes the fixed output current value setting to be
determined and the fixed output pulse setting screen to
[SET]
PPS
be developed automatically
At the same time, the cursor appears.
[EXT] [ENT]
(The digit on which the cursor is positioned is
reverse-displayed.)
STEP9 M3:
FIXED PULSE
ooQoo
Move the cursor to the desired digit using the [SEL] key
and change the numeric value using the [UP] key.
Repeat this operation to change the value to 100 PPS.
[SEL]^[UP]
PPS
When the value has changed to the desired numeric
[U P] [SELl [SETl
value, press the [SET] key to set the value temporarily.
STEP10 M3:
FIXED PULSE
00100
When you press the [SET] key, a message confirming
you whether the setting is OK is displayed.
If OK, press the [SET] key. If you want to redo the
[SET]
OK?
[NO] [SET]
setting, press the [NO] key.
STEP11-1
[NO]
M3:
FIXED PULSE
Soooo
PPS
[UP] [SEL] [SET]
Pressing the [No] key when you are asked "OK?"
causes the numeric value to return to the previous
value and enables you to redo the setting.
STEP11-2(=END) M3:
FIXED PULSE
00100
Pressing the [SET] key when you are asked "OK?"
causes the setting value to be determined.
Then press the [EXT] key. You return to the menu
[SET]
PPS
[EXTl [ENTl
screen.
Note 1: If you set a value beyond the allowable range, 2.4mA or 24mA (in the case of fixed
current output) or 24mA or lOOOOpps (in the case of fixed pulse output) is forcibly set.
Note 2; The pulse width set in Section 8.2.13 is used for fixed pulse output. The pulse width
must not be greater than one half of the fixed output setting frequency. However, the
pulse width will be 40% of fixed output setting frequency if it exceeds lOOOpps.
Note 3: If the fixed output is set to ON, the fixed output current value and fixed output pulse
value setting screen is automatically developed. However, fixed output actually starts
when the fixed output pulse value setting is determined. (If the fixed output current
value and fixed output pulse value are set independently, fixed output starts when the
relevant setting is determined independently.)
-
