TOSHIBA 6 F 8 A 0 8 6 9 ,
Key operation Display example Description
STEP6-1
(NO)
A2;
METER SIZE
mm
Pressing the [NO] key when you are asked “OK?”
causes the number value to return to the previous
value and enables you to redo the setting.
fU PI fSELl [SET]
STEP6-2(=END)
[SET]
A2:
METER SIZE
150
mm
Pressing the [SET] key when you are asked “OK?” con­
firms the setting at this point.
Then if you press the [EXT] key, you return to the menu
screen.
If you press the [ENT] key. you can go to the frequency
change operation starting from the condition of 150mm.
JiXI]________ [END______
Note 1: The meter size display loops as shown below:
®—►2.5mm ► 4mm ------►bmm ----- ► 15mm-----
(2) —►O.linch—►O.lbinch—^ 0.25 inch—K).5inch-----
---- ►óOOmm —KD
---- ►24inch “KD
Note 2: The range unit and the count rate will be forcefully set as shown below when the meter size
is changed. Set each parameter again, if necessary.
Range unit “m/s”
Count rate If the count rate goes out of the setting range when the meter
size is changed, the set value will be forcefully set to zero.
Note 3: The exciting frequency setting may become inappropriate for the set value when the meter
size of the detector is changed. If the exciting frequency is the value shown below when the
meter size is changed, the exciting frequency will be forcefully changed.
Setting meter size Set exciting frequency Forcefully set exciting frequency
(mm) (inch)
2.5 - 200 0 . 1 - 8 —
Not forcefully set
250 - 450 1 0 - 1 8 24Hz 12Hz
500, 600 20, 24 12Hz, 24Hz 6Hz
-
58
-
