TOSHIBA
6,F,8,A0,8,6,9,
Digital Output Active Status (Only for Alarm outputs
Selection item Alarm Output Action
NORMAL CLOSE Normal: contact close. Alarm out; contact open
NORMAL OPEN Normal; contact open, Alarm out; contact close
Digital Input Detective Level
You can select the level of the control signal used for controlling the total counter and pulse
output with digital input, as shown below.
(Only when the digital input function is set to total counter control input)
Selection item Digital input function setting Total counter control signal
L LEVEL
CNT STA/STP
(Total counter START/STOP)
H signal: Totalization STOP
L signal: Totalization START
CNT RES/STA
(Total counter RESET/START)
H signal: Totalization START
L signal: Totalization RESET
H LEVEL
CNT STA/STP
(Total counter START/STOP)
H signal: Totalization START
L signal: Totalization STOP
CNT RES/STA
(Total counter RESET/START)
H signal: Totalization RESET
L signal: Totalization START
Digital output 1 (DOl), digital output 2 (D02) and digital input (DI) can be selected by the
configuration items as follows:
DOl FUNCTN
D02 FUNCTN
DI FUNCTN
DOl ALM STS
D02 ALM STS
DI DET LV
Digital output 1 (DOl)
Digital output 2 (D02)
Digital input
Active status of DOl
Active status of D02
Digital input control signal
-
91
-
