To change the digital I/O functions:
The following example shows how to change the digital output 1 function from high alarm output
(H ALM) to low alarm output (L ALM).
Key operation
Display example
Description
F:
Select "D01 FNUCTN" from the configuration item
MEAS MODE
^D01 FNUCTN
selection screen.
D02 FNUCTN
Dl FUNCTN
D01 ALM STS
D02ALM STS
Dl DET LV
[SEL] [ENT]
STEP1
F1:
The current setting value (H ALM in this example) is
D01FNUCTN
displayed.
HALM
[ENT]
Then press the [ENT] key.
[EXT] [ENT]
* Pressing the [EXT] key returns you to the menu
screen.
STEP2
F1;
The switch name display at the bottom changes
D01FNUCTN
(three keys [UP], [DWN] and [SET])
At the same time, the cursor appears.
[ENT]
[U P] [DWN] [SET]
(The digit on which the cursor is positioned is
reverse-displayed.)
STEP3
F1:
Change the selection item using the [UP]/[DWN]
D01FNUCTN
key.
ireiw
[UP]/[DWN]
[U P] [DWN] [SET]
When you have selected the desired item, press the
[SET] key.
STEP4
F1:
When you press the [SET] key, the selected item is
D01FNUCTN
set temporarily and a message confirming you
L ALM
whether the setting is OK is displayed.
[SET]
OK?
^
If OK, press the [SET] key. If you want to redo the
setting, press the [NO] key.
[NO] [SET]
STEP5-1
F1;
Pressing the [NO] key when you are asked "OK?"
D01 FNUCTN
causes the setting value to return the previous
value and enables you to redo the setting.
[NO]
[U P] [DWN] [SET]
STEP5-2(=END)
F1:
Pressing the [SET] key when you are asked "OK?"
D01FNUCTN
causes the setting value to be determined.
LALM
Press the [EXT] key. You return to the menu
[SET]
screen.
[EXT] [ENT]
Pressing the [ENT] key enables you to restart
setting from a state of LALM.
-
