Section 4: Engine and Transmission Support Asssembly
4 - 10
2.2. Remove the nut, bolt and washer that hold the
upper transmission support to the transmission
using two 9/16” wrenches.
2.3. Remove the upper transmission support.
See Figure 2.3.
2.4. Place a catch pan under the back of the engine
and remove the oil filter. See Figure 2.4.
2.5. Remove the nuts, bolts and washers that hold
the rear of the engine and the engine ground
cable to the engine support assembly using a
pair of 17mm wrenches.
2.6. Reach under the starter motor with a 17mm box
wrench, and position it securely on the one of
the nuts that secure the engine to the engine
support assembly. See Figure 2.6.
2.7. From beneath the Big Country, remove the bolt
that the nut is on using a 17mm wrench.
See Figure 2.7.
2.8. Repeat this process on the final nut and bolt.
2.9. Retrieve the nuts and washers from the engine
support assembly.
Figure 2.3
Upper Transmission Support
Figure 2.4
Oil Filter Ground Cable
Nuts on
Mounting Bolts
Figure 2.6
Oil Drain Valve
Starter Motor
Nuts on Engine
Mounting Bolts
Oil Drain Valve
Engine Mounting
Bolts
Figure 2.7
Rear
Front
