Section 7: Electrical
7 - 2
1.9. The key switch, hour meter, accessory
switches*, warning lights, and front power
port*, are located in the dash panel.
* Where applicable
1.10. There is a bundle of wires at the rear of the
vehicle to accommodate future installation of:
• Electric Bed Lift
• Light Kit
• Rear Power Port
See Figure 1.10.
1.11. Two wires along the top frame member on the
right side of the engine compartment accommo-
date future installation of accessory lighting
and a beacon atop the light bar.
See Figure 1.11.
1.12. The Neutral Safety Switch. See Figure 1.12.
Figure 1.9
Key
Switch
Warning Lights
Hour Meter
Figure 1.10
Bundle of Wires
at the Rear of the
Big Country
Figure 1.11
Power for Light Bar
Figure 1.12
Neutral Safety
Switch
