ORDERING INFORMATION APPENDIX D
D-1
APPENDIX D ORDERING INFORMATION
760-0180 F40 Pump Kit. Includes fully assembled F40 pumpheads with check valves and seals installed,
four F40 piston assemblies, one mixer barrel extender, two mixer O-rings, a 2mm UV flow cell,
PEEK tubing 0.030” (0.76 mm) ID, and necessary tools.
760-0110 F10 Pump Kit. Includes fully assembled F10 pumpheads with check valves and seals installed
and four F10 piston assemblies.
760-0164 F10 Pump Maintenance Kit, services one F10 pumphead. Kit includes two piston seals, four
check valves, seal removal tool, and two O-rings.
760-0161 F10 Piston Seals (2) and Seal Tool. Two piston seals required to service one F10 pump.
760-0162 F10 Piston Assembly (2). Two piston assemblies required to service one F10 pump.
760-0184 F40 Pump Maintenance Kit, services one 40ml pump. Kit includes two piston seals, two check
valves, and two pistons.
760-0172 F40 Piston Seals (2) and Seal Tool. Two piston seals required to service one F40 pump.
750-0162 Check Valve (1). Four check valves required to service one pump; for F10 and F40 pumps.
750-0111 EZ Logic Integration Software Package.
760-2030 USB Bitbus Communicator.
Mixers
760-0170 MX-1 Mixer. Mixer includes mixer body (263µl) and expansion barrel (750µl).
760-0171 MX-1 Mixer Barrel Extender (2ml).
100-1627 MX-1 Mixer Service Kit.
920-8529 MX-1 Mixer Barrel Extender (1) (750µl).
760-2010 Maximizer Mixer. Includes mixer body (750µl), 5ml and 12ml expansion barrels, five O-rings,
stir bar, and installation screws for all barrel sizes.
760-2005 Maximizer Mixer Barrel Extender (5ml).
760-2012 Maximizer Mixer Barrel Extender (12ml).
Detectors
760-1300 QuadTec DuoFlow Detector Kit 100/110, 200/240 V.
Includes QuadTec Detector, 3mm flow cell, System Cable 25 QuadTec RS232 cable, 4x10-32
Fingertight fittings, Instrument Control Module (ICM), System Cable 26 ICM power cable,
System Cable 17 instrument bus cable, QuadTec Instruction Manual, US power cord.
760-1330 QuadTec Deuterium Lamp.
760-1331 QuadTec Halogen Lamp and Holder. The holder is required for first time use.
760-1332 QuadTec Halogen Lamp.
760-1306 QuadTec Flow Cell, PEEK 3mm path length.
760-1311 QuadTec 4x10-32 Long fittings for 3mm flow cell.
760-1406 QuadTec Flow Cell, PEEK High speed for 80 ml/min flow rates.
760-1408 QuadTec 4x10-32 Long fittings for Hi speed flow cell.
760-1301 QuadTec Instruction Manual.
750-0200 UV Detector Kit. Includes UV Detector with 254/280nm filter, 5mm flow cell, conductivity
flowcell, and backpressure regulator.
750-0214 214 nm Conversion Kit (Zinc lamp, housing, 214 nm filter) for Model OM-II UV Detector optics
modules beginning with serial number 362 BR.
750-0215 214 nm Conversion Kit (Zinc lamp, housing, 214 nm filter) for Model OM-IO UV Detector optics
modules, beginning with serial number 345 BR and prior to 362 BR.
750-0210 UV Detector Flow Cell, 2 mm path length.
750-0212 UV Detector Flow Cell, 5 mm path length.
750-0216 Mercury Lamp, replacement.
750-0217 Zinc Lamp (214 nm), replacement.
750-0220 Filter, 280 and 254 nm.
750-0221 Filter, 214 nm.
