Figure 6-3. CopyIn with Information in Browser Tab Window
Move Allows you to transfer a selected Project or Method from one location to another. For
example, a Project can be moved from one User to another, and a Method (and its runs)
can be moved from one project to another. Individual runs cannot be moved. Not that the
selected project, method and run have to be closed before they are moved. To move an
item:
a. Highlight the item in the database tree you want to move. You may highlight a Project or
a Method.
b. Click once on the Move button on the Browser toolbar. The items to be moved will
appear in the MOVE List in the Browser tab window.
c. From the MOVE List, select the items you want to move.
d. From the database tree, select the new destination for the items you are moving.
e. Again click on the Move button. The items will automatically move to the destination.
Hint: Alternatively, highlight the destination icon, right-mouse click and select the “Move
Selected” message with a left-mouse click.
f. Once you finish the move procedure, use the Clear List button on the Browser toolbar to
delete the remaining methods and runs in the MOVE List.
Queue Places methods in a queue. Highlight the method(s) you wish to place in a queue and
select Queue. The methods will appear in the tab screen. Refer to Section 6.3 for detailed
description of queuing.
... All Users [1 user]
...
...
...
...
..............
.........
...
.....
Default.........................................................................................5/20/2001 [1 project]
...
...
.....
...
Default....................................................................................5/20/2001
UNO Q POLISHER 0.25 ML 25 CV [1 run]
Run 1..................................................................8/20/2001 10:59:28 AM
UNO Q POLISHER 1 ML 25 CV [1 run]
UNO Q POLISHER 1 ML 10 CV [1 run]
Run 1..................................................................8/20/2001 9:14:21 AM
..............
...
Copyin Selected Items to Project
New...
Open...
Edit...
Delete...
Print
CopyOut...
CopyIn...
Move
Reset
Queue
Compare
Information MOVE List QUEUES COMPARE COPYIN List Error List
WL1 - 280nm
0.40
WL2 - 260nm
0.15
WL3 - 214nm
2.00
WL4 - 405nm
0.00
Flow Rate EGP %B
0 %B 0.00 ml/min 0%
% Split
1.00ml/min 0 %B2
Maximizer + Gradient Pump: F10 UV Conductivity
438 psi 1.003 AU 1.23 mS/cm
QuadTec
Econo Gradient
Pump
SIM1/pH SIM1/SIG
0.548 Volt 7.00 pH
BioLogic Duo-Flow - - - -
Edit
Method
New
Method
New
Run Browser Manual Setup Protocol
wash
load
1
2
Run Notes Report PostRun Log Settings
Select All
Clear List
File View Utilities Options Window Help
Name Date
Bio-Rad
Web
INTRODUCTION TO THE BROWSER SCREEN SYSTEM OPERATION
6-5
