Table 7-2
Buffer Editor
The Buffer Editor main screen is used to view information about currently defined buffer system and to
create and edit buffer systems.
• Create New Buffer System: This button starts the Buffer System Wizard that is used to create new
buffer systems. Buffers and salts that are defined in the current buffer and salt lists can be used in a
buffer system.
• Edit/View Buffer System: This button starts the Buffer System Wizard and is used to edit, view or
copy existing buffer systems. Buffers and salts that are in the current buffer and salts lists can be
used in a buffer system.
• Edit Buffer List: This button starts a dialog used to create buffer salts that are used in buffer
systems.
• Edit Salt List: This button starts a dialog used create salts that are used in buffer systems.
• Buffer Editor Report: This button allows you to print out buffer system information.
• Export Buffer System: This button allows you to export buffer system information to a text file.
• Close: Exits the Buffer Editor.
• Help: Opens the Buffer Editor online help.
• Delete Buffer System: Deletes the currently selected buffer system. Bio-Rad buffer systems cannot
be deleted.
• View Table: Used to display the pH as a function of % Inlet A2 and %B. Used to determine the pH
range for a buffer. The buffer pH range depends on the salt concentration and should be limited to
the table pH valves shown between 10% and 90% A2.
Buffer Editor
*Acetate (20 mM)
Buffer System:
Name: 2X Concentration:
Buffer(s)
Acetate
Buffer System:
Acetate M 0.04
Name: 2X Concentration:
Salt
Sodium Chloride M 2.00
M
M
3.60 5.60 25.0 (C)
Bio-Rad
Author:
pH Range:
to at
Reference Temperature
Recipe Text
Acetate Acid (40 mM)
Prepare by dissovling:
80 ml of 1M Acetic Acid
in water and diluting to 2.0 L.
Sodium Acetate Trihydrate (40 mM)
Prepare by dissovling:
10.9 g of Sodium Acetate Trihydrate (MW 136.1 g/mol)
in water and diluting to 2.0 L.
Sodium Chloride (2.0 M)
Prepare by dissovling:
233.6 g of Sodium Chloride (MW 58.4 g/mol)
in water and diluting to 2.0 L.
Degassed Water
Degass water under vacuum for at least 15 minutes while stirring
Create New
Buffer System Edit Current
Buffer System
Read Only
Buffer System
Report Export Buffer
System
Delete Buffer
System
View Table
Edit Buffer
List Edit Salt List Close Help
