7.4.1 Pausing/Stopping a Method in Progress
The Run screen provides three options for pausing or stopping a method in progress, as discussed in the
figure below.
Figure 7-6. Run Screen’s Abort, Pause, and Hold Buttons
Pause
Continue Protocol
wash
load
1
2
Stops progression of method, method
time, and pumps. Valves remain in
paused position. From Pause, you can
Continue, Abort, or Edit Protocol. Stops the current run and saves
the data. (A confirmation message
is presented to prevent accidents.)
The run cannot be continued.
To continue the method run. Protocol screen (View only) lets you
view the steps in the run. Select Run
or Edit Protocol. From Run, select
Abort or Continue. Edit Protocol involves
the buttons shown below.
Abort
Stops progression of method and
method time. Pumps continue pumping
at Hold %B concentration, and valves
remain in Hold position. From Hold you
can Continue, Abort, or Pause. You
cannot edit.
Hold
Setup
Run
Setup screen lets you view the list of
devices available to the method. From
Setup, you can select Protocol or Run.
From Run, select Abort or Continue.
Pressing this button initiates the
process of editing the method's protocol.
After editing the method's protocol,
return to the Run screen. You then
can Continue or Abort the run.
Edit
Protocol
wash
load
1
2
hold
alarm
3
4
If there's a run already associated
with the method, the method is
copied and you must rename it.
Method Name:
Method Description:
Method Author:
You may edit the method's protocol
using any of the Add Step buttons
and the Cut, Copy, Paste, and
Delete buttons.
