Industrial PC | Parameter setting & configuration
IPC backup & restore
Software update procedure
74
L
2.5 EN - 01/2012
A software update saved to a USB stick can be copied to the CF card via
»IPC Backup & Restore«.
How to carry out a software update:
1. Connect the USB stick with the software update to the Industrial PC.
2. Restart the Industrial PC.
• The Industrial PC recognises the USB stick and evaluates the control file.
• The software update is carried out automatically if the Install newly created
update option has been selected from the »IPC Backup & Restore« menu under
Windows® XP. In this case, the following steps are unnecessary since the dialog
box is not available.
3. Carry out the calibration
.
• The IPC Backup & Restore dialog appears.
4. Select the required update from the selection list.
5. Click the Update button.
• If you require a backup copy of your present system configuration, click the
Backup button.
6. After the update process has been carried out successfully, the IPC displays a dialog
window for three seconds:
• GUI update done with
Logbook query in the »Engineer«
7. The IPC restarts automatically.
Note!
During the update process, data on the CF card are overwritten.
