Industrial PC | Parameter setting & configuration
Web-based parameterisation with »WebConfig«
User interface
54
L
2.5 EN - 01/2012
7.4.3.2 Filter options
7.4.3.3 Time filter for the display of logbook entries
Section Information
Logbook Display logbook entries
Explanations of the logbook entries, example ( 53)
Time period Select filter for the time period of the logbook entries shown
• The logbook will only display entries which are in the selected time
period.
Application Set filter for the application
• The logbook will only display entries for the selected applications.
Severity Set filter for the severity of the error messages displayed
• The logbook will only display entries that correspond to the selected
degree of severity.
Area Set filter for the origin of the event
• The logbook will only display entries that correspond to the selected area.
Area Filter option Function
Time period 1: All Display all entries
2: From - to Filter entries according to date
specified
3: Last Display last entries only. Possible
filter options:
• 1: Days
• 2: Weeks
• 3: Months
• 4: Years
-from Time zone: Date (Format: Year/
Month/Day), Time (Format: Hours/
Minutes/Seconds)
Example:
10th March 2009, 15.05 hours, 11
seconds: UTC 2009 03 10 15 05 11
Date specification for filtering the
entries to be displayed
• Starting date from which the
entries are to be displayed
-to Time zone: Date (Format: Year/
Month/Day), Time (Format: )
Date specification for filtering the
entries to be displayed
• Target date up to which the
entries are to be displayed
-last 1: Days
2: Weeks
3: Months
4: Years
Display entries according to filter
options.
• To activate this filter option, in the
Time period area of the selection
list the last item must be selected!
