Industrial PC | Parameter setting & configuration
Parameter reference
Industrial PC extension modules
210
L
2.5 EN - 01/2012
Interface parameters of the card in slot 1
C1078
C1080
C1081
C1082
C1083
C1084
C1086
Parameter | Name:
C1078 | Apply IP configuration
Data type: UNSIGNED_16
Index: 23497
d
= 5BC9
h
Code for activating the set configuration. The interface is activated by writing a "1".
Selection list
(Lenze setting printed in bold) Information
1 Activate device
0 No command
; Read access ; Write access CINH PLC STOP ; No transfer
Parameter | Name:
C1080 | Dhcp
Data type: UNSIGNED_32
Index: 23495
d
= 5BC7
h
Activation of the configuration. DHCP states:
• "0" = Inactive
• "1" = Active
If DHCP is active, the codes 21-25 do not have any function
Setting range
(min. value | unit | max. value)
Lenze setting
0 1 1
; Read access ; Write access CINH PLC STOP No transfer
Parameter | Name:
C1081 | IP address
Data type: VISIBLE_STRING
Index: 23494
d
= 5BC6
h
IP address of the interface
; Read access ; Write access CINH PLC STOP No transfer
Parameter | Name:
C1082 | Subnet mask
Data type: VISIBLE_STRING
Index: 23493
d
= 5BC5
h
Subnet mask of the interface
; Read access ; Write access CINH PLC STOP No transfer
Parameter | Name:
C1083 | Default gateway
Data type: VISIBLE_STRING
Index: 23492
d
= 5BC4
h
Default gateway of the interface
; Read access ; Write access CINH PLC STOP No transfer
Parameter | Name:
C1084 | Domain
Data type: VISIBLE_STRING
Index: 23491
d
= 5BC3
h
Domain name of the interface
; Read access ; Write access CINH PLC STOP No transfer
Parameter | Name:
C1086 | MAC address
Data type: VISIBLE_STRING
Index: 23489
d
= 5BC1
h
MAC address (6 8-bit hexadecimal numbers) (e.g. 00:af:13:42:01:a8)
; Read access Write access CINH PLC STOP No transfer
