Lenze PC-based Automation Industrial PC - Manual (Page 170)

Industrial PC | Parameter setting & configuration
Parameter reference
Industrial PC extension modules
170
L
2.5 EN - 01/2012
Parameters of interface 2, card has been installed in slot 2
C1613
C1621
C1622
C1630
C1631
Parameter | Name:
C1613 | Device: Driver index
Data type: UNSIGNED_32
Index: 22962
d
= 59B2
h
Index of the device driver. Since there can be more than one CAN interface, several instances can be run via the
driver.
Display range
(min. value | unit | max. value)
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1621 | Sync master: Interface index
Data type: UNSIGNED_32
Index: 22954
d
= 59AA
h
Note: Restart the IPC after changing this parameter!
Setting range
(min. value | unit | max. value) Lenze setting
4294967295
; Read access ; Write access CINH PLC STOP No transfer
Parameter | Name:
C1622 | Baud rate
Data type: UNSIGNED_32
Index: 22953
d
= 59A9
h
Baud rate of the CAN interface. The value is assigned from a selection list.
Selection list
(Lenze setting printed in bold)
7 5
6 10
5 20
3 50
8 100
2 125
1 250
0 500
4 1000
; Read access ; Write access CINH PLC STOP No transfer
Parameter | Name:
C1630 | Tx PDO counter
Data type: UNSIGNED_32
Index: 22945
d
= 59A1
h
PDO counter for sent CAN messages
Display range
(min. value | unit | max. value)
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1631 | Rx PDO counter
Data type: UNSIGNED_32
Index: 22944
d
= 59A0
h
PDO counter for received CAN messages
Display range
(min. value | unit | max. value)
; Read access Write access CINH PLC STOP No transfer
