Industrial PC | Parameter setting & configuration
Parameter reference
Panel
14.4 Panel
This chapter lists all parameters of the optional panel in numerically ascending order.
C0401
C0402
C0403
C0420
C0421
C0422
Parameter | Name:
C0401 | Device: Type key
Data type: VISIBLE_STRING
Index: 24174
d
= 5E6E
h
Type key of the panel. At the moment only "panel" is defined.
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C0402 | Device: Type version
Data type: VISIBLE_STRING
Index: 24173
d
= 5E6D
h
Version number of the parameter description
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C0403 | Device: Name
Data type: VISIBLE_STRING
Index: 24172
d
= 5E6C
h
Device name of the panel
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C0420 | Panel: Width
Data type: UNSIGNED_16
Index: 24155
d
= 5E5B
h
Horizontal resolution of the panel
Display range
(min. value | unit | max. value)
160 2400
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C0421 | Panel: Height
Data type: UNSIGNED_16
Index: 24154
d
= 5E5A
h
Vertical resolution of the panel
Display range
(min. value | unit | max. value)
100 2000
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C0422 | Dimming value
Data type: UNSIGNED_8
Index: 24153
d
= 5E59
h
Enter the actual brightness value of the display. The numerical values are between the
• maximum = 0 and the
• minimum = 63
Setting range
(min. value | unit | max. value) Lenze setting
0 63 0
; Read access ; Write access CINH PLC STOP ; No transfer
