Industrial PC | Parameter setting & configuration
Parameter reference
Industrial PC extension modules
168
L
2.5 EN - 01/2012
Parameters of interface 1, card has been installed in slot 2
C1573
C1581
C1582
C1590
C1591
Parameter | Name:
C1573 | Device: Driver index
Data type: UNSIGNED_32
Index: 23002
d
= 59DA
h
Index of the device driver. Since there can be more than one CAN interface, several instances can be run via the
driver.
Display range
(min. value | unit | max. value)
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1581 | Sync master: Interface index
Data type: UNSIGNED_32
Index: 22994
d
= 59D2
h
Note: Restart the IPC after changing this parameter!
Setting range
(min. value | unit | max. value) Lenze setting
4294967295
; Read access ; Write access CINH PLC STOP No transfer
Parameter | Name:
C1582 | Baud rate
Data type: UNSIGNED_32
Index: 22993
d
= 59D1
h
Baud rate of the CAN interface. The value is assigned from a selection list.
Selection list
(Lenze setting printed in bold)
7 5
6 10
5 20
3 50
8 100
2 125
1 250
0 500
4 1000
; Read access ; Write access CINH PLC STOP No transfer
Parameter | Name:
C1590 | Tx PDO counter
Data type: UNSIGNED_32
Index: 22985
d
= 59C9
h
PDO counter for sent CAN messages
Display range
(min. value | unit | max. value)
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1591 | Rx PDO counter
Data type: UNSIGNED_32
Index: 22984
d
= 59C8
h
PDO counter for received CAN messages
Display range
(min. value | unit | max. value)
; Read access Write access CINH PLC STOP No transfer
