Industrial PC | Parameter setting & configuration
Parameter reference
Industrial PC extension modules
C1036
C1037
C1038
Interface parameters of the card in slot 1
C1074
C1080/1
C1080/2
C1080/3
Parameter | Name:
C1036 | Device: Serial number
Data type: VISIBLE_STRING
Index: 23539
d
= 5BF3
h
Serial number of the card
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1037 | Device: Manufacturer
Data type: VISIBLE_STRING
Index: 23538
d
= 5BF2
h
Manufacturer of the card
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1038 | Device: Manufacturing date
Data type: VISIBLE_STRING
Index: 23537
d
= 5BF1
h
Manufacturing date of the card
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1074 | ECAT MAC address
Data type: VISIBLE_STRING
Index: 23501
d
= 5BCD
h
MAC address of the interface
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1080/1 | ECAT master config.: Date
Data type: DATE
Index: 23495.1
d
=
0x5BC7.0x01
h
Date of the master configuration file in the file system of the IPC
The data manager refers to the ...\storage\IPC\PLC directory for the date of the master configuration file. If this file
is not available, the date will be displayed as "01/01/1980 00:00:00".
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1080/2 | ECAT master config.: Checksum
Data type: UNSIGNED_32
Index: 23495.2
d
=
0x5BC7.0x02
h
Checksum of the master configuration file in the file system of the IPC
The data manager refers to the master configuration file in the ...\storage\IPC\PLC directory for the checksum. If this
file is not available, the value will be displayed as "0x00000000".
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1080/3 | ECAT stack: Master checksum
Data type: UNSIGNED_32
Index: 23495.3
d
=
0x5BC7.0x03
h
The stack determines the checksum of the loaded/active master configuration file. If no loaded/active master
configuration file is available, the value will be displayed as "0x00000000".
; Read access Write access CINH PLC STOP No transfer
