Industrial PC | Parameter setting & configuration
Parameter reference
Industrial PC extension modules
186
L
2.5 EN - 01/2012
C1096/20
C1096/21
C1096/22
C1096/23
0x0043
MBX_COE
B, P, S, O
Current state + E
0x0044
MBX_FOE
B, P, S, O
Current state + E
0x0045
MBX_SOE
B, P, S, O
Current state + E
0x004F
MBX_VOE
B, P, S, O
Current state + E
Code (hex)
Description
Current state or state
change
Resulting state
Legend:
I: Initialisation
B: Bootstrap (is not supported)
P: Pre-Operational
S: Safe Operational
O: Operational
E: Error-Flag
Parameter | Name:
C1096/20 | ECAT: Active sync pulse
Data type: UNSIGNED_8
Index: 23479.20
d
=
0x5BB7.0x14
h
• Value "0": Sync pulse of distributed clocks not activated on the slave.
• Value "1": Sync pulse of distributed clocks activated on the slave.
Display range
(min. value | unit | max. value)
0
1
;
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1096/21 | ECAT: DC sync 0 period
Data type: UNSIGNED_32
Index: 23479.21
d
=
0x5BB7.0x15
h
Period in which setpoints are expected to be received from the control system if the distributed clocks support has
been switched-on.
Display range
(min. value | unit | max. value)
0
4294967295
;
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1096/22 | ECAT: DC sync 1 period
Data type: UNSIGNED_32
Index: 23479.22
d
=
0x5BB7.0x16
h
Distributed clocks sync 1 period
Note: At present, distributed clocks are not used on the sync 1 of Lenze slaves.
Display range
(min. value | unit | max. value)
0
4294967295
;
Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1096/23 | ECAT: Bus scan error code
Data type: UNSIGNED_32
Index: 23479.23
d
=
0x5BB7.0x17
h
Error code after bus scan
The parameter has the value "0" if the configuration and the slave are identical. In the event of an error, however,
e.g. error code 0x9811001E
hex
(bus scan mismatch) is saved here.
Display range
(min. value | unit | max. value)
0
4294967295
;
Read access Write access CINH PLC STOP No transfer
