Industrial PC | Parameter setting & configuration
Parameter reference
Industrial PC extension modules
C1586/5
C1586/6
C1586/7
C1586/8
C1586/9
C1586/10
Parameter | Name:
C1586/5 | ECAT config.: Numb. slaves
Data type: UNSIGNED_32
Index: 22989.5
d
=
0x59CD.0x05
h
Number of slaves configured in the master configuration file
Display range
(min. value | unit | max. value)
0 4294967295
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1586/6 | ECAT config.: Numb. mailbox slaves
Data type: UNSIGNED_32
Index: 22989.6
d
=
0x59CD.0x06
h
Number of mailbox slaves configured in the master configuration file
Display range
(min. value | unit | max. value)
0 4294967295
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1586/7 | ECAT counter: Tx frames
Data type: UNSIGNED_32
Index: 22989.7
d
=
0x59CD.0x07
h
Number of sent frames
Display range
(min. value | unit | max. value)
0 4294967295
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1586/8 | ECAT counter: Rx frames
Data type: UNSIGNED_32
Index: 22989.8
d
=
0x59CD.0x08
h
Number of received frames
Display range
(min. value | unit | max. value)
0 4294967295
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1586/9 | ECAT counter: Lost frames
Data type: UNSIGNED_32
Index: 22989.9
d
=
0x59CD.0x09
h
Number of lost frames
Display range
(min. value | unit | max. value)
0 4294967295
; Read access Write access CINH PLC STOP No transfer
Parameter | Name:
C1586/10 | ECAT counter: Cyclic frames
Data type: UNSIGNED_32
Index: 22989.10
d
=
0x59CD.0x0A
h
Number of cyclic frames
Display range
(min. value | unit | max. value)
0 4294967295
; Read access Write access CINH PLC STOP No transfer
