Chapter 4: SNMPv1 and SNMPv2c
88 Section I: Basic Operations
Displaying the SNMP Community Strings
To display the attributes of all the SNMP community strings on the switch,
use the following procedure:
1. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 4 on page 46.
2. From the System Administration menu, type 5 to select SNMP
Configuration.
The SNMP Configuration menu is shown in Figure 16 on page 79.
3. From the SNMP Configuration menu, type 4 to select Display SNMPv1
& SNMPv2c Community.
The Display SNMPv1 & SNMPv2c Community menu is shown in
Figure 19.
Figure 19. Display SNMP Community Menu
For attribute definitions, refer to “SNMPv1 and SNMPv2c Overview” on
page 76.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Display SNMPv1 & SNMPv2c Community
Community Name Access Mode Status OpenAcc Manager IP Addr Trap Receiver IP
=================================================================================
Private125
Read|Write Enabled No 147.41.11.30 147.45.16.70
147.45.16.80 147.45.16.80
PublicATI78 Read Only Enabled No 147.41.11.12 147.42.22.22
147.44.16.86 147.45.16.86
147.45.16.88 147.45.16.88
147.45.16.90 147.45.16.90
HighSchool2 Read|Write Enabled No 147.45.10.80 147.45.10.80
U - Update Display
R - Return to Previous Menu
Enter your selection?
