AT-S63 Management Software Menus Interface User’s Guide
Section I: Basic Operations
175
Displaying the TCP Global Information
The TCP Global Information table displays TCP status and statistics. To
view the table, perform the following procedure:
1. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 4 on page 46.
2. From the System Administration menu, type 9 to select System
Utilities.
The System Utilities menu is shown in Figure 7 on page 53.
3. From the System Utilities menu, type 6 to select Networking Stack.
The Networking Stack menu is shown in Figure 50 on page 165.
4. From the Networking Stack menu, type 6 to select Display TCP Global
Information.
The Display TCP Global Information menu is shown in Figure 55.
Figure 55. Display TCP Global Connections Menu
The Display TCP Global Connections menu contains the following
items of information:
RTO min (ms) and RTO max (min)
Retransmit time algorithm parameters.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager
11:20:02 02-Mar-2005
Display TCP Global Information
TCP MIB parameters, counters
-------------------------------------
RTO min (ms):
1000
RTO max (ms):
240000
Max connections:
-1
Active Opens:
0
Passive Opens:
0
Attempt Fails:
0
Established Resets:0
Current Established:
0
In Segs:
0
In Segs Error:
0
Out Segs:
0
Out Segs Retran:
0
Out Segs with RST:
0
U - Update Display
R - Return to Previous Menu
Enter your selection?
