Chapter 26: Protected Ports VLANs
630
Section V: VLANs
Displaying a Protected Ports VLAN
To view the name, VID number, and member ports of all the VLANs on a
switch, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 198 on page 561.
2. From the VLAN Configuration menu, type 6 to select Show VLANs.
The Show VLANs menu is shown in Figure 225.
Figure 225. Show VLANs Menu
3. To view additional information about a particular protected ports
VLAN, type D to select Detail Information Display.
The following prompt is displayed:
Enter new value ->
4. Enter the VID of the protected ports VLAN whose information you want
to view.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager
11:20:02 02-Mar-2005
Show VLANs
VID
VLAN Name
VLAN Type
Protocol
Untagged (U) / Tagged (T)
------------------------------------------------------------------------
1
Default_VLAN
Port Based
U:
Port Based
T: 9
4
Sales
Port Based
U: 1-7
Port Based
T: 9
5
Internet VLAN Protected
U: 11-25
Protected
T:
N - Next Page
U - Update Display
D - Detail Information Display
R - Return to Previous Menu
Enter your selection?
