AT-S63 Management Software Menus Interface User’s Guide
Section I: Basic Operations 123
Displaying Port Status
To display the current status of the ports on the switch, perform the
following procedure:
1. From the Main Menu, type 1 to select Port Configuration.
The Port Configuration menu is shown in Figure 25 on page 102.
2. From the Port Configuration menu, type 2 to select Port Status.
An example of the Port Status menu is shown in Figure 33.
Figure 33. Port Status Menu
Note
The speed, duplex mode, and flow control settings are blank for a
port that has not established a link with its end node.
The Port Status menu displays a table that contains the following
columns of information:
Port
The port number.
Link
The status of the link between the port and the end node connected to
the port. The possible settings are:
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Port Status
Port Link Neg MDIO Speed Duplex PVID PortType
----------------------------------------------------------------
17
Up Auto MDI 10 Half 0001 10/100/1000Base-T
18 Up Auto MDI 100 Full 0001 10/100/1000Base-T
19 Up Auto MDI 100 Full 0001 10/100/1000Base-T
20 Up Auto MDI 100 Full 0001 10/100/1000Base-T
21 Up Auto MDI 10 Half 0001 10/100/1000Base-T
22 Up Auto MDI 100 Full 0001 10/100/1000Base-T
23 Up Auto NA NA Full 0001 1000Base-X SFP
24 Up Auto MDI 1000 Half 0001 1000Base-X
P - Previous Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
