Chapter 23: Port-based and Tagged VLANs
568 Section V: VLANs
Enter new value -> [1 to 4096] ->
5. Enter the VID of the VLAN you want to modify.
The Modify VLAN menu expands to contain all relevant information
about the VLAN, as shown in Figure 202.
Figure 202. Expanded Modify VLAN Menu
6. Adjust the following parameters as necessary.
1 - VLAN Name
This parameter changes the name of a VLAN. The name can be from
one to fifteen alphanumeric characters in length. The name should
reflect the function of the nodes that will be a part of the VLAN (for
example, Sales or Accounting). The name cannot contain spaces or
special characters, such as asterisks (*) or exclamation points (!).
When you change a VLAN’s name, observe the following guidelines:
ˆ A VLAN’s new name cannot be the same as the name of another
VLAN on the same switch. For example, if the switch already
contains a VLAN called Sales, you cannot change an existing
VLAN’s name to Sales.
ˆ You cannot change the name of the Default_VLAN.
Note
A VLAN must have a name.
2 - VLAN ID (VID)
This is the VLAN’s VID value. You cannot change this value.
3 - Tagged Ports
Use this selection to add or remove tagged ports from the VLAN. You
can specify the ports individually (e.g., 2,3,5), as a range (e.g., 7-9), or
both (e.g., 2,5,7-9).
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Modify VLAN
1 - VLAN Name .............. Sales
2 - VLAN ID (VID) .......... 3
3 - Tagged Ports ........... 7,9
4 - Untagged Ports ......... 20-24
M - Modify VLAN
R - Return to Previous Menu
Enter your selection?
