Chapter 16: Quality of Service

306

Section II: Advanced Operations

application. The components of the policies are shown in Figure 104.

Figure 104. QoS Voice Application Example

Create Classifier

01 - Classifier ID: ..... 22
02 - Description ....... VoIP flow
.
.
12 - Src IP Addr ....... 149.44.44.44
13 - Src IP Mask ......

Create Flow Group

1 - Flow Group ID ............. 14
2 - Description ................... VoIP
3 - DSCP Value .................
4 - Priority ......................... 7
5 - Remark Priority ........... No
6 - Classifier List .............. 22

Create Traffic Class

01 - Traffic Class ID: ........ 18
02 - Desciption ................ VoIP flow
.
.
A - Flow Group List ......... 14

Create Policy

1 - Policy ID: .................. 6
2 - Desciption ................ VoIP flow
.
.
5 - Traffic Class List ......... 18
6 - Ingress Port List ......... 1

Create Classifier

01 - Classifier ID: ..... 23
02 - Description ....... VoIP flow
.
.
14 - Dst IP Addr ....... 149.44.44.44
15 - Dst IP Mask .......

Create Flow Group

1 - Flow Group ID ............. 17
2 - Description ................... VoIP
3 - DSCP Value .................
4 - Priority ......................... 7
5 - Remark Priority ........... No
6 - Classifier List .............. 23

Create Traffic Class

01 - Traffic Class ID: ........ 15
02 - Desciption ................ VoIP flow
.
.
A - Flow Group List ......... 17

Create Policy

1 - Policy ID: .............. 11
2 - Desciption ............ VoIP flow
.
.
5 - Traffic Class List ..... 15
6 - Ingress Port List ...... 8

Policy 6

Policy 11
