AT-S63 Management Software Menus Interface User’s Guide
Section II: Advanced Operations 327
7. To delete another traffic class, repeat this procedure starting with step
4.
8. After making changes, type R until you return to the Main Menu. Then
type S to select Save Configuration Changes.
Displaying
Traffic Classes
To display the traffic classes, perform the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
2. From the Security and Services menu, type 6 to select Quality of
Service.
The Quality of Service (QoS) menu is shown in Figure 108 on page
313.
3. From the Quality of Service (QoS) menu, type 2 to select Traffic Class
Configuration.
The Traffic Class Configuration menu is shown in Figure 115 on page
320.
4. From the Traffic Class Configuration menu, type 4 to select Show
Traffic Classes.
The Show Traffic Classes menu is shown in Figure 119.
Figure 119. Show Traffic Classes Menu
5. To display the specifics of a traffic class, type D to select Display
Traffic Class Details.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Show Traffic Classes
Number of Traffic Classes: 5
Associated
ID Description Policy ID
------------------------------------------------
0
Dev database
1 Inv database
2 Video1
3 Video2
4 Demo dev
D - Display Traffic Class Details
U - Update Display
R - Return to Previous Menu
Enter your selection?
