AT-S63 Management Software Menus Interface User’s Guide
Section IV: Spanning Tree Protocols 493
Configuring RSTP
This section contains the following procedures:
ˆ ”Configuring RSTP Bridge Settings”, next
ˆ “Configuring RSTP Port Settings” on page 495
Configuring
RSTP Bridge
Settings
This section contains the procedure for configuring a bridge’s RSTP
settings.
Caution
The default RSTP parameters are adequate for most networks.
Changing them without prior experience and an understanding of
how RSTP works might have a negative effect on your network. You
should consult the IEEE 802.1w standard before changing any of the
RSTP parameters.
To configure the RSTP bridge settings, perform the following procedure:
1. From the Main Menu, type 3 to select Spanning Tree Configuration.
The Spanning Tree Configuration menu is shown in Figure 169 on
page 485.
2. From the Spanning Tree Configuration menu, type 3 to select
Configure Active Protocol.
The RSTP menu is shown in Figure 174.
Figure 174. RSTP Menu
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
RSTP Menu
1 - Force Version .......... RSTP
2 - Bridge Priority ........ 32768 (In multiples of 4096: 8)
3 - Bridge Hello Time ...... 2
4 - Bridge Forwarding ...... 15
5 - Bridge Max Age ......... 20
6 - Bridge Identifier ...... 00:30:84:00:00:00
P - RSTP Port Parameters
D - Reset RSTP to Defaults
R - Return to Previous Menu
Enter your selection?
