Chapter 6: Port Parameters
102 Section I: Basic Operations
Configuring Port Parameters
To configure the most basic parameter settings for a port, perform the
following procedure:
1. From the Main Menu, type 1 to select Port Configuration.
The Port Configuration menu is shown in Figure 25.
Figure 25. Port Configuration Menu
2. From the Port Configuration menu, type 1 to select Port Configuration.
The following prompt is displayed:
Enter port-list ->
3. Enter the number of the port you want to configure. You can specify
more than one port at a time. You can specify ports individually (for
example, 5,7,22), as a range (for example, 18-23), or both (for
example 1,5,14-22). You cannot specify nonconsecutive ports (for
example, 5,7,9).
Note
To configure SFP or GBIC port 23 or 24 on an AT-9424 switch, the
port must have a valid link to an end node. If no SFP or GBIC is
installed or if it does not have a valid link, your configuration
changes affect the corresponding twisted pair port, 23R or 24R. You
cannot configure twisted pair port 23R or 24R if its corresponding
SFP or GBIC port has a valid link to an end node.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Port Configuration
1 - Port Configuration
2 - Port Status
3 - Port Statistics
4 - Port Trunking and LACP
5 - Port Security
6 - Port Mirroring
R - Return to Previous Menu
Enter your selection?
