AT-S63 Management Software Menus Interface User’s Guide
Section I: Basic Operations 161
Displaying the Port Mirror
To display the port mirror, perform the following procedure:
1. From the Main Menu, type 1 to select Port Configuration.
The Port Configuration menu is shown in Figure 25 on page 102.
2. From the Port Configuration menu, type 6 to select Port Mirroring.
The Port Mirroring menu is shown in Figure 49.
Figure 49. Port Mirroring Menu
The Port Mirroring menu provides the following information about the
port mirror:
Enable/Disable
The port mirroring status, Enabled or Disabled.
Mirror-To (Destination) Port
The port that functions as the destination port.
Ingress (Rx) Mirror (Source) Port
The port(s) where ingress (received) traffic is mirrored.
Egress (Tx) Mirror (Source) Port
The port(s) where egress (transmitted) traffic is mirrored.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Port Mirroring
1 - Enable/Disable ...................... Enabled
2 - Mirror-To (Destination) Port ........ 22
3 - Ingress (Rx) Mirror (Source) Ports .. 1,3
4 - Egress (Tx) Mirror (Source) Ports ... 11-13
R - Return to Previous Menu
Enter your selection?
