AT-S63 Management Software Menus Interface User’s Guide
Section IV: Spanning Tree Protocols 499
2. From the Spanning Tree Configuration menu, type 3 to select
Configure Active Protocol.
The RSTP menu is shown in Figure 170 on page 487.
3. From the RSTP menu, type P to select RSTP Port Parameters.
The RSTP Port Parameters menu is shown in Figure 175 on page 495.
4. From the RSTP Port Parameters menu, type 3 to select Display RSTP
Port State.
The Display RSTP Port State menu is shown in Figure 178.
Figure 178. Display RSTP Port State Menu
The Display RSTP Port State menu displays a table that contains the
following information:
Port
The port number.
State
The RSTP state of the port. The possible states are:
Discarding - The port is discarding received packets and is not
submitting forwarded packets for transmission.
Learning - The port is enabled for receiving, but not forwarding
packets.
Forwarding - Normal operation.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Display RSTP Port State
Port State Role P2P Version Port-Cost
--------------------------------------------------------------
1 Disabled
2
3
4
5
6
7
8
1
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
