Chapter 13: Classifiers
266 Section II: Advanced Operations
Displaying Classifiers
To display the classifiers on a switch, do the following:
1. From the Main Menu, type 7 to select Security and Services.
The Security and Services menu is shown in Figure 82 on page 259.
2. From the Security and Services menu, type 1 to select Classifier
Configuration.
The Classifier Configuration menu is shown in Figure 83 on page 260.
3. From the Classifier Configuration menu, type 4 to select Show
Classifiers.
An example of the Show Classifiers menu is shown in Figure 86.
Figure 86. Show Classifiers Menu
The Show Classifiers menu displays the current classifiers in a table
with the following columns of information:
ID
The classifier’s ID number.
Description
The description of the classifier.
Number of References
The number of active and inactive ACL and QoS policy assignments
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Show Classifiers
Number of classifiers: 5
ID Description Number of Number of
References Active Associations
------------------------------------------------------
1
IP flow 4 3
2 Dst149.11.11.0 1 1
3 TCP flow 1 0
4 Src149.22.22.49 1 1
5 ToS 6 2 2
D - Detail Classifier Display
U - Update Display
R - Return to Previous Menu
Enter your selection?
