AT-S63 Management Software Menus Interface User’s Guide
Section II: Advanced Operations 333
Available Policy(ies): 0-4
Enter Policy ID : [0 to 255] -> 0
5. Enter the ID number of the policy you want to modify. You can modify
only one policy at a time.
The Modify Policy menu is shown in Figure 123.
Figure 123. Modify Policy Menu
6. Modify the settings as needed. For parameter definitions, refer to
“Creating a Policy” on page 330.
When you modify a policy, note the following:
ˆ You cannot change the traffic class ID number.
ˆ To delete a value from a variable so as to leave it blank, select the
variable and then use the backspace key to delete its default value.
ˆ Specifying an invalid value for a parameter that already has a value
causes the parameter to revert to its default value.
7. Type M to select Modify Policy.
Modifications to a policy are immediately activated on the ports where
the policy is assigned.
8. To modify another policy, repeat this procedure starting with step 4.
9. After making changes, type R until you return to the Main Menu. Then
type S to select Save Configuration Changes.
Deleting a Policy
To delete a policy, perform the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Modify Policy
1 - Policy ID ............ 0
2 - Description .......... video
3 - Remark DSCP .......... None
4 - DSCP value ........... 7
5 - Traffic Class List ... 0
6 - Redirect Port ........ 1
7 - Ingress Port List .... 22
8 - Egress Port .......... 3
M - Modify Policy
R - Return to Previous Menu
Enter your selection?
