Chapter 17: Class of Service
344 Section II: Advanced Operations
The Class of Service (CoS) menu is shown in Figure 126.
Figure 126. Class of Service (CoS) Menu
The “Number of CoS Queues” line indicates the number of egress
queues each port has. On the AT-8500 Series switch, there are four
queues per port. This value cannot be changed.
3. From the Class of Service menu, type 1 to select Configure Port CoS
Priorities.
The following prompt is displayed:
Enter port number -> [1 to 24] ->
4. Enter the number of the port on the switch where you want to configure
CoS. You can specify only one port at a time.
The Configure Port COS Priorities menu is shown in Figure 127.
Figure 127. Configure Port COS Priorities Menu
Menu option 1 cannot be changed.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Class of Service (CoS)
Number of CoS Queues: 4
1 - Configure Port CoS Priorities
2 - Map CoS Priority to Egress Queue
3 - Configure Egress Scheduling
4 - Show Port CoS Priorities
R - Return to Previous Menu
Enter your selection?
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Configure Port COS Priorities
1 - Port Number ................... 1
2 - Priority (0-7) 0=Low 7=High ... 0
3 - Override Priority (Y/N) ....... N
C - Configure COS Priorities
R - Return to Previous Menu
Enter your selection?
