Chapter 16: Quality of Service
308 Section II: Advanced Operations
Video Applications
Video applications typically require a larger bandwidth than voice
applications. Video applications can be set up to have a high priority and
buffering, depending on the application.
This example creates policies with low latency and jitter for video streams
(for example, net conference calls). The policies in Figure 105 assign the
packets a priority level of 4 and limit the bandwidth to 5 Mbps. The node
containing the application has the IP address 149.44.44.44. Policy 17 is
assigned to port 1, where the application is located, and Policy 32 is
assigned to port 8 where packets destined to the application enter the
switch.
Figure 105. QoS Video Application Example
The parts of the policies are:
Create Classifier
01 - Classifier ID: ..... 16
02 - Desciption ......... Video flow
.
.
12 - Src IP Addr ....... 149.44.44.44
13 - Src IP Mask .......
Create Flow Group
1 - Flow Group ID ............. 41
2 - Description ................... Video
3 - DSCP Value .................
4 - Priority ......................... 4
5 - Remark Priority ........... No
6 - Classifier List .............. 16
Create Traffic Class
1 - Traffic Class ID: ........ 19
2 - Desciption ................ Video
.
.
6 - Max Bandwidth ........ 5
.
.
A - Flow Group List ....... 41
Create Policy
1 - Policy ID: ................ 17
2 - Desciption .............. Video flow
.
.
5 - Traffic Class List ....... 19
6 - Ingress Port List ....... 1
Create Classifier
01 - Classifier ID: ..... 42
02 - Desciption ......... Video flow
.
.
12 - Dst IP Addr ........ 149.44.44.44
13 - Dst IP Mask .......
Create Flow Group
1 - Flow Group ID ............. 36
2 - Description ................... Video
3 - DSCP Value .................
4 - Priority ......................... 4
5 - Remark Priority ........... No
6 - Classifier List .............. 42
Create Traffic Class
1 - Traffic Class ID: ........ 21
2 - Desciption ................ Video
.
.
6 - Max Bandwidth ........ 5
.
.
A - Flow Group List ....... 36
Create Policy
1 - Policy ID: ................ 32
2 - Desciption .............. Video flow
.
.
5 - Traffic Class List ....... 21
6 - Ingress Port List ....... 8
Policy 17 Policy 32
