AT-S63 Management Software Menus Interface User’s Guide
Section IV: Spanning Tree Protocols 489
Configuring STP
Port Settings
To adjust STP port parameters, perform the following procedure:
1. From the Main Menu, type 3 to select Spanning Tree Configuration.
The Spanning Tree Configuration menu is shown in Figure 169 on
page 485.
2. From the Spanning Tree Configuration menu, type 3 to select
Configure Active Protocol.
The STP menu is shown in Figure 170 on page 487.
3. From the STP menu, type P to select STP Port Parameters.
The STP Port Parameters menu is shown in Figure 171.
Figure 171. STP Port Parameters Menu
4. Type 1 to select Configure STP Port Settings.
The following prompt is displayed:
Start Port to Configure [1 to 26] ->
5. Enter the number of the port you want to configure. To configure a
range of ports, enter the first port of the range.
The following prompt is displayed:
End Port to Configure [1 to 24] ->
6. To configure just one port, enter the same port number here as you
entered in the previous step. To configure a range of ports, enter the
last port of the range.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
STP Port Parameters
1 - Configure STP Port Settings
2 - Display STP Port Configuration
R - Return to Previous Menu
Enter your selection?
