Allied Telesis AT-S63 - Manual (Page 773)

AT-S63 Management Software Menus Interface User’s Guide
Section VII: Management Security 773
Displaying RADIUS Status and Settings
To display the RADIUS status and settings, perform the following
procedure:
1. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 4 on page 46.
2. From the System Administration menu, type 6 to select Authentication
Configuration.
The Authentication Configuration menu is shown in Figure 269 on
page 765.
3. From the Authentication Configuration menu, type 4 to select RADIUS
Configuration.
The RADIUS Client Configuration menu is shown in Figure 272 on
page 771.
4. From the RADIUS Client Configuration menu, type 6 to select Show
Status.
The Show Status menu is shown in Figure 274.
Figure 274. Show Status Menu
The Show Status menu displays a table that contains the following
columns of information:
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Show Status
Global Configuration
--------------------
Encryption Key : ATI
Server Timeout: 30 second(s)
Server IP Address Auth Port Encryption Key Auth Req Auth Resp
---------------------------------------------------------------
149.11.11.11
1812 WRRT 100 96
149.22.22.22 1812 LLST 4 4
149.22.22.22 1812 OORT 0 0
U - Update Display
R - Return to Previous Menu
Enter your selection?
