AT-S63 Management Software Menus Interface User’s Guide
Section II: Advanced Operations 317
9. After making changes, type R until you return to the Main Menu. Then
type S to select Save Configuration Changes.
Deleting a Flow
Group
To delete a flow group, perform the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
The Security and Services menu is shown in Figure 82 on page 259.
2. From the Security and Services menu, type 6 to select Quality of
Service.
The Quality of Service (QoS) menu is shown in Figure 108 on page
313.
3. From the Quality of Service (QoS) menu, type 1 to select Flow Group
Configuration.
The Flow Group Configuration menu is shown in Figure 109 on page
314.
4. From the Flow Group Configuration menu, type 3 to select Destroy
Flow Group.
The following prompt is displayed:
Available Flow Group(s): 0-10
Enter Flow Group ID : [0 to 1023] -> 0
5. Enter the ID number of the flow group you want to delete. You can
delete only one flow group at a time.
The Destroy Flow Group menu is shown in Figure 112.
Figure 112. Destroy Flow Group Menu
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Destroy Flow Group
1 - Flow Group ID .............. 2
2 - Description ................ Video1
3 - DSCP value ................. 0
4 - Priority ................... 6
5 - Remark Priority ............ No
6 - Classifier List ............ 11
D - Destroy Flow Group
R - Return to Previous Menu
Enter your selection?
