Chapter 16: Quality of Service
314 Section II: Advanced Operations
The Flow Group Configuration menu is shown in Figure 109.
Figure 109. Flow Group Configuration Menu
4. From the Flow Group Configuration menu, type 1 to select Create
Flow Group.
The Create Flow Group menu is shown in Figure 110.
Figure 110. Create Flow Group Menu
5. Configure the following parameters as desired:
1 - Flow Group ID
Specifies an ID number for the flow group. Each flow group on the
switch must have a unique number. The range is 0 to 1023. The
default is 0. This parameter is required.
2 - Description
Specifies a description for the flow group. The description can be from
1 to 15 alphanumeric characters including spaces. This parameter is
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Flow Group Configuration
1 - Create Flow Group
2 - Modify Flow Group
3 - Destroy Flow Group
4 - Show Flow Groups
R - Return to Previous Menu
Enter your selection?
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Create Flow Group
1 - Flow Group ID ..............
2 - Description ...............
3 - DSCP value ................
4 - Priority ..................
5 - Remark Priority ...........
6 - Classifier List ...........
C - Create Flow Group
R - Return to Previous Menu
Enter your selection?
