AT-S63 Management Software Menus Interface User’s Guide
Section V: VLANs 607
The GVRP State Machine menu (page 2) is displayed, as shown in
Figure 220.
Figure 220. Display GVRP State Machine Menu (page 2)
The information in the menu is defined in Table 20. This information is
for viewing purposes only.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
GVRP State Machine
State Machine for VLAN: 1
Port App Reg | Port App Reg | Port App Reg | Port App Reg |
------------------------------------------------------------------
1 Aa Fix | 2 Aa Fix | 3 Vo Mt | 4 Vo Fix |
5 VO Fix | 6 Vo Fix | 7 VO Mt | 8 Vo Fix |
9 Vo Fix | 10 Vo Fix | 11 Vo Mt | 12 Vo Fix |
13 Vo Fix | 14 Vo Fix | 15 Vo Mt | 16 Vo Fix |
17 Aa Fix | 18 Vo Fix | 19 Vo Mt | 20 Vo Fix |
21 Vo Mt | 22 Vo Mt | 23 Aa FIx | 24 Aa Fix |
-----------------------------------------------------------------
U - Update Display
R - Return to Previous Menu
Enter your selection?
Table 20. GVRP State Machine Parameters
Parameter Meaning
Port Port number on the switch; this port belongs to
the GARP application. If the GARP application
has no ports, “No ports have been assigned” is
displayed.
